Exoplanet Classification using Kepler Space Telescope Data

# Data manipulation
import pandas as pd

# Data visualization
import matplotlib.pyplot as plt

# Feature selection
from sklearn.pipeline import Pipeline
from sklearn.impute import SimpleImputer
from sklearn.feature_selection import VarianceThreshold
from sklearn.feature_selection import SelectKBest

# Training and evaluating classifiers
from sklearn.model_selection import cross_validate
from sklearn.preprocessing import StandardScaler
from sklearn.pipeline import make_pipeline
from sklearn.linear_model import LogisticRegression
from sklearn.ensemble import RandomForestClassifier
from sklearn.svm import SVC

# Saving model
import os
import joblib


def get_data():
    # Download .csv from NASA Exoplanet Archive and save as exoplanets.csv
    # https://exoplanetarchive.ipac.caltech.edu/cgi-bin/TblView/nph-tblView?app=ExoTbls&config=cumulative

    # Read data, skipping comment lines
    df = pd.read_csv('exoplanets.csv', comment='#', index_col='kepid')
    return df


def explore_data():
    df = get_data()
    print('Shape of dataframe (rows, columns):\t', df.shape)

    # Describe numeric columns
    stats = df.describe()
    print(stats)

    # Describe non-numeric columns
    cols = df.columns.difference(stats.columns)
    info = df[cols].describe()
    print(info)

    # Visualize histogram of disposition column
    df['koi_disposition'].hist()
    plt.title('Distribution of koi_disposition')
    plt.xlabel('koi_disposition')
    plt.ylabel('Frequency')
    plt.show()


def clean_df(df):
    # Remove empty columns
    df.dropna(axis=1, how='all', inplace=True)

    # Remove empty rows
    df.dropna(how='all', inplace=True)

    # Remove duplicate rows
    df.drop_duplicates(inplace=True)

    # Remove sparse rows
    df.dropna(thresh=df.shape[1] * 0.5, inplace=True)


def select_features(df):
    # Split feature (X) and target (y) values
    target = 'koi_disposition'
    y = df[target]
    X = df.drop(target, axis=1)

    # Drop non-numeric columns (not features)
    count0 = X.shape[1]
    X = X.drop(columns=X.select_dtypes(exclude='number').columns)
    print(f'Removed {count0 - X.shape[1]} non-numeric columns')

    # Drop sparse columns (more than 10% missing values)
    count0 = X.shape[1]
    X = X.dropna(axis=1, thresh=int(0.9 * len(X)))
    print(f'Removed {count0 - X.shape[1]} sparse columns')

    # Unsupervised feature selection methods

    # Remove features with low variance
    count0 = X.shape[1]
    selector = VarianceThreshold(threshold=0.01)
    selector.fit_transform(X)

    # get_support() returns a boolean mask of selected features
    X = X[X.columns[selector.get_support()]]
    print(f'Removed {count0 - X.shape[1]} low variance features')

    # Analyze pairwise correlations between remaining features
    # corr() default calculates the Pearson correlation coefficient
    # remove redundant variables based on correlation
    matrix = X.corr()

    # Set a threshold for correlation (e.g., 0.9)
    threshold = 0.9

    # Find highly correlated features
    cols = set()
    for i in range(len(matrix.columns)):
        for j in range(i+1, len(matrix.columns)):
            if abs(matrix.iloc[i, j]) > threshold:
                cols.add(matrix.columns[i])

    X = X.drop(cols, axis=1)
    print(f'Removed {len(cols)} correlated features')

    # Supervised feature selection method

    # Input missing values and perform
    # ANOVA feature selection for numeric features and categorical target
    # TIP: Try different values for strategy and k to improve performance
    pipeline = Pipeline([
        ('imputer', SimpleImputer(strategy='mean')),
        ('feature_selection', SelectKBest(k=10))
    ])
    X = pipeline.fit_transform(X, y)

    return X, y


def compare_classifiers(X, y, classifiers):
    scoring = {
        'accuracy': 'accuracy',
        'precision': 'precision_macro',
        'recall': 'recall_macro',
        'f1': 'f1_macro'
    }

    results = {}
    for name, clf in classifiers.items():
        pipeline = make_pipeline(StandardScaler(), clf)
        cv = cross_validate(pipeline, X, y, scoring=scoring, return_train_score=False)
        results[name] = {
            metric: cv[f'test_{metric}'] for metric in scoring.keys()
        }

    mean_scores = pd.DataFrame({
        name: {metric: scores.mean() for metric, scores in clf_results.items()}
        for name, clf_results in results.items()
    }).T

    std_scores = pd.DataFrame({
        name: {metric: scores.std() for metric, scores in clf_results.items()}
        for name, clf_results in results.items()
    }).T

    summary = pd.concat([mean_scores, std_scores], keys=['Mean', 'Std'], axis=1)

    return summary


def save_best_mean(X, y, scores, classifiers, save_dir):
    # Find the best classifier based on mean accuracy
    score = scores['Mean']['accuracy'].max()
    name = scores['Mean']['accuracy'].idxmax()
    clf = classifiers[name]

    # Train the best classifier on the entire dataset
    pipeline = make_pipeline(StandardScaler(), clf)
    pipeline.fit(X, y)

    # Save the best model with name and score for reference
    os.makedirs(save_dir, exist_ok=True)
    save_path = f'{save_dir}/{name}_{score:.2f}.joblib'
    joblib.dump(pipeline, save_path)

    return save_path


def train_model(X, y):
    # Classifier selection
    # TIP fine tune classifier parameters to improve performance
    classifiers = {
        'logistic_regression': LogisticRegression(),
        'random_forest': RandomForestClassifier(),
        'svm': SVC()
    }

    # Evaluating classifiers
    performance = compare_classifiers(X, y, classifiers)
    print(performance)

    # Training & saving model
    model_path = save_best_mean(X, y, performance, classifiers, 'models')
    print(f"Best model saved to {model_path}")

    return model_path


def serve_model(model_path, X_new):
    model = joblib.load(model_path)
    predictions = model.predict(X_new)
    return predictions


def main():
    # Data collection & pre-processing
    df = get_data()
    clean_df(df)
    print('Shape of dataframe after cleaning:\t', df.shape)

    # Feature selection
    # Returns X: a numpy.ndarray of Features
    #         y: a pandas series of Labels
    X, y = select_features(df)
    print('Shape of filtered features\t', X.shape)

    # The train_model function will save the best model and return its path
    model_path = train_model(X, y)

    # In subsequent runs, you can set the path manually
    # model_path = 'models/random_forest_0.83.joblib'

    # Example - serving a single prediction
    sample = X[0].reshape(1, -1)
    prediction = serve_model(model_path, sample)
    print(f'Prediction = {prediction[0]}')
    print(f'Actual     = {y.iloc[0]}')

    # Example - serving multiple predictions
    samples = X[:3]
    predictions = serve_model(model_path, samples)
    print(f'Predictions = {predictions}')
    print(f'Actual      = {y.values[:3]}')

    # When making predictions with the loaded model:
    # New data should have the same number of features as the training data.
    # The input should be a 2D array, even for a single sample
    # Hence the reshape(1, -1) in the example


if __name__ == '__main__':
    # Uncomment this to optionally explore the data prior to training
    # explore_data()

    main()
